Red Color Fm200 Gas Cylinder For 4.2 / 5.6MPa Fire Suppression System

Product Details:
Place of Origin: China
Brand Name: xingjin
Payment & Shipping Terms:
Minimum Order Quantity: 300 sets
Price: negotiable
Packaging Details: Plywood case
Delivery Time: 10-15 days
Payment Terms: L/C, D/P, T/T, Western Union, Paypal, Credit card
Supply Ability: 3000 sets per month

Detail Information

Capacity: 70L / 90L / 100L Ect. Outside Diameter(mm): 267
Height(mm): 139 Net Weight(kg): 139
Color: Red Material: Steel

Product Description

Red Color Several Size Fm200 Gas Cylinder For 4.2/5.6MPa Fire Suppression System





Parameter



  40L 70L 90L 100L 120L 150L 180L
Nominal volume(L) 40 70 90 100 120 150 180
Actual volume(L) 40.5 70.5 90.5 100.5 120.6 150.5 180.6
Internal diameter(mm) 300 350 350 350 350 400 400
Total length(mm) 770 930 1140 1244 1454 1405 1644
Filling medium FM200+nitrogen
Filling capacity(kg) 46.4 81.2 104.4 116 139.2 174 208.8
Designed thickness of cylinder(mm) 5.4 6.3 6.3 6.3 6.3 7.2 7.2
Designed thickness of head(mm) 4.8 5.7 5.7 5.7 5.7 6.5 6.5
Material standard GB6653-2008
Specified value of chemical ingredients of material

C≤0.20% Si≤0.35% Mn≤1.50%

P≤0.025% S≤0.015% P+S≤0.04%

Material strength specified value

Rm 510~620MPa

Rel ≥345MPa

Net weight of cylinder(excluding detachable part)(kg) 38 63 76 82.5 95.5 122 138
Test of hydraulic pressure 8.4MPa
Test of sealing pressure 5.6MPa





Description



The fm200 gas cylinder is made with carbon steel and used to store the fm200 agent that is in liquid condition. This cylinder is different in size, volume as well as the storage pressure. No matter which size of cylinder, there are only two kinds of storage pressures -- 4.2MPa and 5.6MPa. Besides, all these cylinders can be used in all kinds of fire suppression system not just for fm200 fire suppression system.
