50L Automatic FM200 Fire Extinguisher Enclosed Flooding FM200 Gas Suppression System for Commercial Use

Product Details

Place of Origin: China

Brand Name: xingjin

Certification: CAL,CMA,CNAS,ILAC-MRA,CCC

Payment & Shipping Terms

Minimum Order Quantity: 2 set system

Price: negotiation

Packaging Details: Plywood outer box with bubble bag or paper

Delivery Time: 15-20 working days after payment or receipt of L/C

Payment Terms: T/T, L/C

Supply Ability: 30000 set system

Get Best Price

Product Details

Product Description

Product Details

Highlight:
                                                                                                                                                                                                                                                fm200 fire extinguisher, automatic fire extinguisher ball


Volume:	50L	Capacity Of Agent:	50kg
Spraying Time:	≤8s	Pattern Of Extinguishing:	Enclosed Flooding
Working Temperature:	0～50℃	Standard Of Examination:	GB25972-2010

Volume:	50L
Capacity Of Agent:	50kg
Spraying Time:	≤8s
Pattern Of Extinguishing:	Enclosed Flooding
Working Temperature:	0～50℃
Standard Of Examination:	GB25972-2010

Product Description

Technical Specifications

No.	Specification	Technical Parameter
1	Filling Pressure	1.6 MPa
2	Spraying Time	≤ 8 s
3	Working Temperature	0 – 50 °C
4	Starting Mode	Automatic

Product Description

FM-200 (HFC-227ea) is a colorless, odorless, non-corrosive, and electrically insulating gas that leaves no residue or pollution after extinguishing. Its Ozone Depletion Potential (ODP) is zero, making it an environmentally friendly extinguishing agent. These properties also make it suitable for special locations where electrical fires are likely to occur.

Using a small glass tube and the contraction principle, the device operates as an automatic fire extinguisher without any manual manipulation.

Working Principle

When a fire occurs, the two types of hanging FM-200 fire suppression systems activate in different ways:

Electromagnetic Hanging Type FM-200 Fire Suppression System

A fire occurs → A smoke/heat detector activates and sends a signal to the control panel → The control panel receives the signal and activates the alarm bell to notify people to quickly escape from the building → The control panel receives both signals from the smoke and heat detectors, then activates the electromagnetic hanging type FM-200 fire suppression system.

Temperature-Based Hanging Type FM-200 Fire Extinguisher

A fire occurs → The temperature climbs rapidly → The temperature exceeds the specified threshold of the temperature-sensing glass bulb → The temperature-sensing glass bulb bursts under high temperature → The FM-200 fire agent is discharged from the cylinder through the nozzle to extinguish the fire.

Competitive Advantages

This system is highly efficient for protecting your property. As a complete system, it includes an extinguishing device that puts out fire in a short time — specifically, in less than eight seconds. This means all agent is discharged in that brief period, flooding the entire protected area.

The FM-200 automatic fire extinguisher is easy to install and saves considerable space after installation. It is also more cost-effective since it requires no matching electrical accessories or pipe fittings. It is suitable for small rooms and multiple zones.

Simulated Diagram

Important Notes

The entire fire suppression system requires at least one inspection per year. Some components should be checked weekly, others monthly, and the complete system annually. This frequency follows our manual instructions and professional recommendations.
One protected zone should install at most one temperature-based hanging type FM-200 fire extinguisher. During a fire, temperature differences may prevent multiple units from activating simultaneously, which could result in an insufficient amount of fire agent to extinguish the fire.
