CO2 Fire Extinguisher for Fire Detected Tube Extinguisher Factory direct quality assurance best price

Product Details

Place of Origin: China

Brand Name: xingjin

Payment & Shipping Terms

Minimum Order Quantity: 100 sets

Price: negotiation

Packaging Details: Plywood case

Delivery Time: 10-15 days

Payment Terms: L/C, D/P, T/T, Western Union, Paypal, Credit c ard

Supply Ability: 3000 sets per month

Get Best Price
Product Details
High Light:

fire fighting extinguishers

,

fm200 extinguisher

Volume:
70L
Nominal Pressure:
5.7Mpa
Max Working Pressure:
12.1Mpa
Working Temperature:
0℃-49℃
Material:
Aluminum Steel
Printed Color:
Red
Volume:
70L
Nominal Pressure:
5.7Mpa
Max Working Pressure:
12.1Mpa
Working Temperature:
0℃-49℃
Material:
Aluminum Steel
Printed Color:
Red
Product Description

42kg CO2 Fire Extinguisher for Fire Detected Tube Extinguisher


Description:

This device can detect fire situation by a pressurized fire trace tube, which connecting to an extinguishing agent storage. Both HFC-227ea/FM200 or Carbon Dioxide can be used as extinguishing agent for this device.

Usually, it would be designed to two modes of discharge----direct release and indirect release. When fire breaks out, the fire trace will activate the device, and spray extinguishing agent through the fire trace tube itself, we call it direct release. And another mode, the fire trace tube will detect fire, and extinguishing agent is discharge through a pre-installed pipe and nozzle quickly, we call it indirect release.

Fire trace extinguishing device is a good device with covering the shortage of fixed device. Because it can be used in a small space or area of special environment which cannot install pipeline, nozzles, or fire alarm system.


Parameter:


NO.Type of DeviceDirect Type Fire Detecting Tube CO2 Fire Suppression DeviceIndirect Type Fire Detecting Tube CO2 Fire Suppression DeviceDirect Type Fire Detecting Tube FM200 Fire Suppression Device
1Device modelWZ-Q/T-EZ6-XJ60WZ-Q/T-EJ42-XJ60WZ-Q/T-QZ3-XJ60
2Storage Pressure
(20℃)
5.17Mpa5.17Mpa2.5Mpa
3Max. Working Pressure12.1Mpa12.1Mpa4.2Mpa
4Min. Agent Needed for A Unit2.5kg/m³1.5kg/m³0.7kg/m³
5Max Agent Capacity6kg42kg3kg
6Max. Length of Fire Tube25m25m20m
7Max. Length of Release Tube--12m--
8Max. Filling Rate0.6kg/L0.6kg/L1.12kg/L
9Working temperature0℃~49℃0℃~49℃0℃~50℃


CO2 Fire Extinguisher for Fire Detected Tube Extinguisher Factory direct quality assurance best price 0

Components:

This extinguishing device needs no electrical elements and pipe fittings to consist of a system. It can be a fire suppression system itself.

The direct type fire detecting tube fire suppression system is consist of a cylinder, an at most 25m long fire detecting tube, a container valve and two kinds of agents-- co2 and fm200.

The indirect type fire detecting tube fire suppression system has the same components as the direct type except a release tube added. In this system, the fire detecting tube is used for just detecting function, so it needs a release tube together, however, for the direct type, the fire detecting tube can be used for both detecting and releasing.

Advantages:

The fire detecting tube fire suppression device has the following advantages:

1. Convenient installation and transportation. Because this system combines fire fighting and alarm function together, and no needs to match electrical elements and pipe fittings, so after fixing the cylinder on a place, all left to do is fixing the detecting tube around a potential source of fire.

2. Non-electric start mode. It doesn’t need the power to activate the system. This system’s work principle is using its own storage pressure instead of relying on the outside force activating. When the detecting tube is broken by the fire, the agent will discharge.

3. Little occupation of space. This system is suitable for protecting a system, like telecommunication system, rather than a protected zone. The cylinder fixes on the outer cabinet, and will not occupy many places.


Certificate

Environmental Management System Certificate
Occupational Health and Safety Management System Certificate
Quality Management System Certificate
Certificate of China Compulsory Product Certification


Packages
We always pack it with polyfoam first and then put it into a wooden case. Sometimes, in order to meet with customers or the safety requirement, we will make a pallet for the goods.

Company Introduction:
Guangzhou Xingjin Fire Equipment Co., Ltd., which is situated in Guangzhou, which is a key hub for communication between China and the rest of the globe, is surrounded by easy access to transit and a stunning natural environment. We are a manufacturer, and our professional and experienced staff, which includes the program design team, the skillful installation team, the quality detecting team, and the after-sell service team, devotes its time to the study and development of HFC-227ea (FM200) products. The pipe network FM200 fire suppression system, the cabinet type FM200 fire suppression system, the automatic FM200 fire extinguisher (ceiling mounted style), the fire detecting tube suppression system, and the automatic fire suppression tube are currently among the most commonly utilized of our well-known FM200 products. As a result of high-quality products and services as well as the good reputation, our company is well-received by the customers in China. CO2 Fire Extinguisher for Fire Detected Tube Extinguisher Factory direct quality assurance best price 1

Part Cases Show:
• In Sichuan province, the project cases are Bei Xin Run Yuan, Dong Lu Yi Jing, Yuewang Tower, Times Flower City, Shude Middle School, Wal - Mart near ASCB, New Hope Building, Xin Yi Zi Jin City, Tobacco Building, etc.
• In Guangdong province, the project cases are GAC Group, 10086 in Shenzhen, Haizhu Industrial and Commercial Bureau, Wanbao Air Controller, Yingfu Building in Shenzhen, Bank of Communication in Zhanjiang, Lijin Square in Zhanjiang, Zhanjiang Broadcasting and TV Station, etc.
• In Shandong province, the project cases are Lushang Office Building, Lushang Marketing Center, etc.

Why Choose Us
• 5 years quality guarantee
• Xingjin is running in a high efficiency management system
• Advanced equipments & professional engineers to promise all products are quite satisfactory.
• We provide 8×6 hrs technical support and service.
After-Sale Service
• We have an efficient sales and after sales team to promise slove all client's question in time.
• We provide 8×6 hrs technical support and service.
FAQ
Q1: Are you a trading company or a manufacturing, first?
A1: We are a producer.

Q2: Do OEM items exist?
A2: Your own artwork and design are appreciated.

Q3: Where is your factory located? Can I go there?
A3: Shilou, Panyu, Guangzhou, Guangdong, China is where our factory is located. Yes, of course. We always look forward to seeing you.

Q4: How can I get to your plant ?
A4: You can take a taxi or take the subway to get here because of how easily it can be reached. If arriving by subway, you must take the line 4 and alight at the Shiqi station. Take the No. 126 bus out of the station after that, and get off at Yuexi station.
