Economical Fm200 Automatic Fire Suppression System Environmentally Friendly Clean Agent

Product Details

Place of Origin: China

Brand Name: Xingjin

Certification: CAL,CMA,CNAS,ILAC-MRA,CCC

Payment & Shipping Terms

Minimum Order Quantity: 2 set system

Price: negotiation

Packaging Details: Plywood outer box with bubble bag or paper

Delivery Time: 15-20 working days after payment or receipt of L/C

Payment Terms: T/T, L/C

Supply Ability: 30000 set system

Get Best Price
Product Details
Highlight:
Filling Pressure:
4.2Mpa / 5.6Mpa
Colour:
Red
Storage Pressure:
≤950kg/m3
Capacity:
70L / 90L / 100L / 120L / 150L / 180L
Filling Pressure:
4.2Mpa / 5.6Mpa
Colour:
Red
Storage Pressure:
≤950kg/m3
Capacity:
70L / 90L / 100L / 120L / 150L / 180L
Product Description

     Economical Fm200 Automatic Fire Suppression System Environmentally Friendly

                                                                        Clean Agent





Parameter



 - Filling Pressure : the product usually has two kinds of filling pressure, one is 4.2Mpa and the other is

   5.6Mpa



 - Spraying Time : usually less than 10s



 - Scale of A Protected Zone : the system can cover at most 800m2 in proportion as well as 3600m3 in

   volume



 - The Quantity of Protected Zone : at most 8 units



 - Condition of Reserving Room : the adeqaute temperature for this room is between -10℃ and 50℃. Also

   the relative humidity can not go beyond 97%



 - Power : the system will start operation when the voltage reach DC24V with 1.6A current



 - Nitrogen - Pressure Driving Device : Under 20℃, the pressure of this device is 6.0 ± 1.0Mpa





Composition



This system seems very sophisticated and hard to understand well. However, here will analyze it for you completely by graph.

















Pros and cons



Here will show you guys the advantages and the points that need to be noticed.



Advantages :



1/ It just requires little places for storage



2/ It is cost-efficient when the protected zone is large



3/ It is environmentally friendly and isn't potentially harmful to the environment and ozone layer



4/ Safer for your possessions because of its short spraying time



5/ It doean't leaves residue so you don't need to clean it up



Points you need to know :



1/ This system can at most protect 8 zones



2/ Every half year, the system needed to have a whole check to make sure if it is fine





Applications



Our system is suitable for a lot of places, especially the significant and large places. The followings are just some of them taken for examples.
