Nontoxic Colorless Heptafluoropropane Agent In Fire Suppression System

Product Details:
Place of Origin: China
Payment & Shipping Terms:
Minimum Order Quantity: 1000 kg
Price: negotiable
Packaging Details: Tank
Delivery Time: 10-15 working days after payment or receipt of L/C
Payment Terms: L/C, T/T, D/P, Western Union,Paypal,Credit Crad,Debit Card
Supply Ability: 50000 kg per month
  • Detail Information
  • Product Description

Detail Information

Satyrated Vapor Density 20℃(kg/m3): 31.18 Burner Extinguishing Concentration: 5.80
Minimal Extinguishing Concentration: 7.00 Acidity as HF: 3 Ppm Max
NOAEL: 9.00
High Light:

fm200 fire suppression


fire extinguisher fm200

Product Description

Nontoxic Colorless Heptafluoropropane Agent Used In Fire Suppression System





HFC-227ea, another name FM200, is a kind of odorless and colorless halocarbon in a gaseous state. Nowadays, it is normally used in two situations. One is used as a clean agent in fire suppression system, the other is used in pharmaceutical metered dose inhalers such as those used for dispensing asthma medication.

As a clean agent in fire suppression system, it can put out B, C types, and electrical type fires. To put out a fire, the concentration requires between 6.25% and 9% in an occupied space without mandated egress time, or up to 10.5% for a limited time, because the NOAEL level shows that FM200 agent turns to toxic when the concentration reaches 10.5%.

Because of lacking chlorine or bromine atoms, FM200 agent will not hurt the ozone layer, and its ODP is 0%. Besides, its atmospheric lifetime is between 31 and 42 years.


Nontoxic Colorless Heptafluoropropane Agent In Fire Suppression System 0




Specifications Parameters
Physical State Liquefied gas under pressure
Color Colorless
pH Neutral
Boiling Range/Point(℃/℉) -16.4℃/3℉
Melting Point(℃/℉) -129.5℃/265℉
Flash Point(PMCC)(℃/℉) Not Flammable
Vapor Pressure

540hPa at -30℃

29,360hPa at 123℃

Vapor Density(Air=1) 5.8




Function and Application:


    Fm200 is a clean gas agent which can be completely vaporized without residue in the atmosphere and is good at electric insulation of gas phase. And it is suitable for extinguishing electric fire by way of total flooding or fusible solid, liquid, solid surface firefighting. It can be applied to the computer room, communication room, transformer room, precise instrument room, generator room, oil depot, chemical inflammable material warehouse and online library, library, archives, Treasury and other places. Fm200 fire extinguishing system with reasonable structure and reliable operation, has been widely used in computer rooms, archives, program-controlled exchange room, TV broadcasting center and financial institutions, government agencies, and other important places.

Nontoxic Colorless Heptafluoropropane Agent In Fire Suppression System 1





1. clean gas agent

2. colorless, tasteless, low toxicity, and non-conductive

3. no residue or oily deposits

4. small storage space and easily pressurized in cylinder

5. compliance with environmental protection requirement

6. Large range of application area

7. perfect protection of apparatus or zones

8. no damage to equipment or device

9. simple disposal with ventilation
