Non Corrosive FM200 Fire Suppression System Without Pollution For Library

Product Details

Place of Origin: China

Brand Name: Xingjin / OEM

Certification: CAL,CMA,CNAS,ILAC-MRA,CCC

Model Number: QMP40/4.2, QMP70/4.2, QMP100/4.2, QMP120/4.2, QMP150/4.2, QMP180/4.2

Payment & Shipping Terms

Minimum Order Quantity: 2 set system

Price: negotiation

Packaging Details: Plywood outer box with bubble bag or paper

Delivery Time: 15-20 working days after payment or receipt of L/C

Payment Terms: T/T, L/C

Supply Ability: 30000 set system

Get Best Price
Product Details
High Light:

FM200 Fire Suppression System Non Corrosive

,

Manual FM200 Fire Suppression System

,

Hfc-227ea Fire Suppression System

Cylinder Volume:
40L, 70L, 90L, 100L, 120L, 150L, 180L
Capacity Of Gas:
38kg, 66.5kg, 85.5kg, 95kg, 114kg, 142.5kg, 171kg
Pattern Of Extinguishing:
Enclosed Flooding
Agent:
Hfc-227ea (FM200)
Working Pressure:
4.2MPa / 5.6MPa
Color:
Red
Discharge Time:
≤10s
Power:
DC24V/1.5A
Starting Mode:
Automatic, Electrical Manual, Mechanical Emergency Manual
Product Name:
Fm200 Fire Suppression System
Cylinder Volume:
40L, 70L, 90L, 100L, 120L, 150L, 180L
Capacity Of Gas:
38kg, 66.5kg, 85.5kg, 95kg, 114kg, 142.5kg, 171kg
Pattern Of Extinguishing:
Enclosed Flooding
Agent:
Hfc-227ea (FM200)
Working Pressure:
4.2MPa / 5.6MPa
Color:
Red
Discharge Time:
≤10s
Power:
DC24V/1.5A
Starting Mode:
Automatic, Electrical Manual, Mechanical Emergency Manual
Product Name:
Fm200 Fire Suppression System
Product Description

Non Corrosive FM200 Fire Suppression System Without Pollution for Library

Description



     Though Fm200 is a new and small part of the gas fire-fighting, it becomes more and more popular all over the world. Because of its born advantages-odorless, colorless and nontoxic, fm200 fire suppression system is considered as the best substitute of the popular series of halon type fire suppression system. The most attractive point is that the fm200 fire suppression system has no damage to the ozone layer, even just 1% possibility. Though the whole system looks very complicated, actually it is easy to install.



     This Fm200 fire fighting equipment only fits the occupied room or places, because it uses whole flooding way to extinguish the fire.



Parameters



NO. Specifications 4.2Mpa system 5.6Mpa system
1 Capacity 40Ltr,70Ltr,100Ltr,120Ltr,150Ltr,180Ltr 70Ltr,90Ltr,120Ltr
2 Device model QMP40/4.2, QMP70/4.2, QMP100/4.2,QMP120/4.2, QMP150/4.2, QMP180/4.2 QMP70/5.6, QMP90/5.6, QMP120/5.6
3 Filling pressure 4.2Mpa 5.6Mpa
4 Max filling rate 0.95kg/L 1.08kg/L
5 Discharge time ≤10s
6 Power DC24V/1.5A
7 Nitrogen driving device 6.0±1.0Mpa
8 Storage surroundings Temperature:-10~50℃
Relative humidity:≤97%
9 Proportion ≤800m²
10 Volume ≤3600m³





Non Corrosive FM200 Fire Suppression System  Without Pollution For Library 0Non Corrosive FM200 Fire Suppression System  Without Pollution For Library 1



Components



      The pipe network model of fm200 fire suppression system consists of three parts: the pipe network part, the fire fighting equipment part and the electrical elements part. Here will explain the last two parts for customers.


      The main part of the system is fire fighting equipment. It is formed by several components: fm200 cylinder, a cylinder frame, nitrogen-pressure driving device, a driving device frame, container valves, flexible hoses, liquid flow check valves, gas control pipes, gas flow check valves, manifolds, safety valves, selective valves, flanges, elbows and nozzles.



      The electrical elements is a set of detecting device, and it always plays a subsidiary role in each system. The electrical elements includes: control panel, manual button, discharge indicator light, alarm bells, sounder with light, smoke detector and heat detector.





Non Corrosive FM200 Fire Suppression System  Without Pollution For Library 2

Non Corrosive FM200 Fire Suppression System  Without Pollution For Library 3


Application


                                             •     Computer room, communication room, power distribution room, library, archives, Museum, etc.



                                            •     Be used for electrical fire, liquid fire, solid fire, gas fire which can be cut off the gas source before extinguishing occur, etc.





Packages



We always pack it with polyfoam firstly and then put it into a wooden case. Sometimes, in order to meet with customers or the safety requirement, we will make a pallet for the goods.



                                                                Non Corrosive FM200 Fire Suppression System  Without Pollution For Library 4    Non Corrosive FM200 Fire Suppression System  Without Pollution For Library 5
