CO2 Fire Suppression System For Oxygen - Deficient Environment

Product Details

Place of Origin: China

Brand Name: xingjin

Certification: CAL,CMA,CNAS,ILAC-MRA,CCC

Model Number: QME70

Payment & Shipping Terms

Minimum Order Quantity: 1 set of system

Price: negotiation

Packaging Details: Plywood case or box case

Delivery Time: 10-15 working days

Payment Terms: L/C, D/P, T/T, Western Union, Paypal, Credit card

Supply Ability: 3000 sets per month

Get Best Price
Product Details
Highlight:

CO2 Fire Suppression System For Oxygen

,

Enclosed Flooding CO2 Fire Suppression System

Nitrogen Pressure Of Driving Device:
6.0±1.0Mpa(20℃)
Spraying Time:
≤60s
Pattern Of Extinguishing:
Enclosed Flooding
Working Pressure:
5.7MPa
Cylinder Volume:
70L
Capacity Of Agent:
42kg
Type:
Pipe Network
Starting Mode:
Automatic, Electrical Manual, Mechanical Emergency Manual
Nitrogen Pressure Of Driving Device:
6.0±1.0Mpa(20℃)
Spraying Time:
≤60s
Pattern Of Extinguishing:
Enclosed Flooding
Working Pressure:
5.7MPa
Cylinder Volume:
70L
Capacity Of Agent:
42kg
Type:
Pipe Network
Starting Mode:
Automatic, Electrical Manual, Mechanical Emergency Manual
Product Description

High pressure CO2 fire extinguishing system



Description:



A form of fire suppression system called a CO2 fire extinguishing system employs carbon dioxide gas (CO2) to put out fires. This technology is frequently used to safeguard sensitive facilities like data centers, electrical equipment rooms, and other places where water or other types of fire suppression chemicals can cause harm.

A storage cylinder or bank of cylinders carrying pressurized CO2 gas, linked pipework, and discharge nozzles make up the conventional CO2 fire extinguisher system. The CO2 gas is released from the cylinders and piped to the discharge nozzles, where it is directed toward the fire, when the system is turned on manually or automatically.

The oxygen in the air is replaced when the CO2 gas is released, resulting in an oxygen-deficient environment that suffocates the fire. By absorbing heat and bringing the temperature of the surrounding air down, CO2 gas can also be used to effectively put out a fire.

Based on the size, kind, and potential fire threats of the covered area, CO2 fire extinguishing systems are often created to satisfy specific fire protection criteria. Local fire codes or insurance companies frequently mandate these systems for particular kinds of facilities or operations. The performance and safety of CO2 fire extinguisher systems depend on proper installation, upkeep, and operation.



Parameter:



No. Specification Technical Parameter
1 Device Model QME70
2 Capacity 70Ltr
3 Filling Volume of Gas 42kg
4 Working Pressure 5.7MPa
5 Max Working Pressure 12.4MPa
6 Spraying Time ≤60s
7 Max Filling Rate 0.6kg/L
8 Power DC24V/1.6A
9 Working Pressure of Releasing Device Container Valve: 19±0.95MPa;
Manifold: 15±0.75MPa
10 Nitrogen Pressure of Driving 6.0±1.0Mpa(20℃)
11 Condition of Reserving Room for Container Temperature: 0~50℃



CO2 Fire Suppression System For Oxygen - Deficient Environment 0








Components



The three major components of the pipe network type CO2 automatic fire suppression system are described below. Electrical accessories, pipe fittings, and extinguishing equipment.

Extinguishing devices include items like CO2 cylinders for storing fuel, frames with driving devices (nitrogen cylinders) that cause the storage cylinders to release agents, and so on.

Pipe fittings, which include high pressure galvanized steel pipe, flanges, elbows, and other components, are conduits used to link extinguishing equipment and agents that direct fire into protective zones.

Electrical accessories are those items that are used to detect and monitor the entire protective area, regulate the entire system, alert people to flee, and stop the spread of fire.

These three combined components work well together to automatically detect, monitor, alarm, and put out fires.



CO2 Fire Suppression System For Oxygen - Deficient Environment 1CO2 Fire Suppression System For Oxygen - Deficient Environment 2



Applications:



    Library and archives room, electronic computer room, electrical substation, telecommunication room, hangar, garage, marine engine room, cargo, paint-spraying room, boiler room, control center, etc.

It is suitable for putting out all kinds of the fires of flammable liquid and solid matter; gas fire in which power can be cut off before extinguishing the fire.
