Home > products > FM200 Fire Suppression System > Secure Your Archive With Red FM200 Automatic Fire Suppression Extinguishing System 4.2Mpa 40L

Secure Your Archive With Red FM200 Automatic Fire Suppression Extinguishing System 4.2Mpa 40L

Product Details

Place of Origin: China

Brand Name: Xingjin / OEM

Certification: CAL,CMA,CNAS,ILAC-MRA,CCC

Model Number: QMP40/4.2, QMP70/4.2, QMP100/4.2, QMP120/4.2, QMP150/4.2, QMP180/4.2

Payment & Shipping Terms

Minimum Order Quantity: 2 set system

Price: negotiation

Packaging Details: Plywood outer box with bubble bag or paper

Delivery Time: 15-20 working days after payment or receipt of L/C

Payment Terms: T/T, L/C

Supply Ability: 30000 set system

Get Best Price
Product Details
High Light:

40L Fire Suppression Extinguishing System

,

FM200 Automatic Fire Suppression Extinguishing System

Cylinder Volume:
40L, 70L, 90L, 100L, 120L, 150L, 180L
Capacity Of Gas:
38kg, 66.5kg, 85.5kg, 95kg, 114kg, 142.5kg, 171kg
Pattern Of Extinguishing:
Enclosed Flooding
Agent:
Hfc-227ea (FM200)
Working Pressure:
4.2MPa / 5.6MPa
Color:
Red
Discharge Time:
≤10s
Power:
DC24V/1.5A
Starting Mode:
Automatic, Electrical Manual, Mechanical Emergency Manual
Product Name:
Fm200 Fire Suppression System
Cylinder Volume:
40L, 70L, 90L, 100L, 120L, 150L, 180L
Capacity Of Gas:
38kg, 66.5kg, 85.5kg, 95kg, 114kg, 142.5kg, 171kg
Pattern Of Extinguishing:
Enclosed Flooding
Agent:
Hfc-227ea (FM200)
Working Pressure:
4.2MPa / 5.6MPa
Color:
Red
Discharge Time:
≤10s
Power:
DC24V/1.5A
Starting Mode:
Automatic, Electrical Manual, Mechanical Emergency Manual
Product Name:
Fm200 Fire Suppression System
Product Description

Red FM200 Fire Suppression System with 4.2Mpa System for Archive 40L

Description


  1. The Red FM200 Fire Suppression System is a highly efficient and advanced fire suppression solution designed to protect critical assets and sensitive environments. This system operates at a pressure of 4.2 MPa (megapascals), ensuring a rapid and effective response to fire emergencies.
  2. The FM200 agent used in this system is a clean and environmentally friendly fire suppressant, known for its exceptional extinguishing properties. It quickly suppresses fires by removing heat and interrupting the chemical chain reaction, preventing the spread of flames and minimizing damage to valuable assets.
  3. The Red FM200 Fire Suppression System is engineered with precision, incorporating cutting-edge technology and industry-leading components. It consists of a storage container, a high-pressure release valve, a piping network, and strategically placed nozzles or diffusers. When a fire is detected, the system is activated, releasing the FM200 agent through the nozzles or diffusers into the protected area.
  4. The 4.2 MPa pressure rating ensures that the FM200 agent is discharged at a high velocity, effectively reaching the fire source and filling the protected space rapidly. This quick response time greatly reduces the potential for fire escalation and limits the associated damage.
  5. The system is designed to be highly reliable, with comprehensive safety features and strict adherence to international fire suppression standards. It is suitable for a wide range of applications, including data centers, server rooms, control rooms, archives, museums, and other areas where sensitive equipment or valuable assets are present.


Parameters



NO. Specifications 4.2Mpa system
1 Capacity 40Ltr,70Ltr,100Ltr,120Ltr,150Ltr,180Ltr
2 Device model QMP40/4.2, QMP70/4.2, QMP100/4.2,QMP120/4.2, QMP150/4.2, QMP180/4.2
3 Filling pressure 4.2Mpa
4 Max filling rate 0.95kg/L
5 Discharge time ≤10s
6 Power DC24V/1.5A
7 Nitrogen driving device 6.0±1.0Mpa
8 Storage surroundings Temperature:-10~50℃
Relative humidity:≤97%
9 Proportion ≤800m²
10 Volume ≤3600m³




Secure Your Archive With Red FM200 Automatic Fire Suppression Extinguishing System 4.2Mpa 40L 0

































































































Components




1. FM200 storage container: FM200 gas is kept in this pressurized container. Safety features are installed in the container to guard against too much pressure. It can be constructed using a variety of materials, including composites and steel.



2.FM200 release valve: When a fire is detected, this valve allows the FM200 gas to be released into the enclosed space. A fire detection system may automatically open the valve or it may be activated manually.



3. From the storage container to the secure site, the FM200 gas is transported via this pipe system. Gas is evenly distributed throughout the pipework to effectively put out fires.



4.Nozzles: To introduce FM200 gas into the confined space, use this equipment. To ensure that the gas is spread properly and effectively to put out the fire, the nozzle design is essential.



5.Fire detecting system: This technique is used to find out whether there is a fire in an area after it has been given the all-clear. It is possible to program the FM200 release valve to open automatically in the presence of flame, heat, or smoke.



6. Control panel: The control panel monitors the system and regulates the release of the FM200 gas. The panel can be utilized for system testing and maintenance operations.

Secure Your Archive With Red FM200 Automatic Fire Suppression Extinguishing System 4.2Mpa 40L 1

Secure Your Archive With Red FM200 Automatic Fire Suppression Extinguishing System 4.2Mpa 40L 2









































































































Application



When an area has been granted the all-clear, this method is utilized to determine whether there is a fire there. The FM200 release valve can be programmed to activate automatically in the presence of flame, heat, or smoke.



The system is watched over and the release of the FM200 gas is controlled by the control panel. The panel can be used for system maintenance and testing procedures.



-IT server rooms: Since these locations house essential computer servers and other electronic devices, FM200 fire suppression systems are an excellent fit for them. The clean agent gas won't harm electronic equipment and can put out fires safely.



-Telecommunications facilities: For big sites that hold telecommunications equipment, fire suppression systems are frequently necessary. Flames that could damage the vital communication infrastructure can be put out by the FM200 system.





-Museums and art galleries: These locations frequently have priceless, priceless artifacts that should be preserved. Fires can be put out by FM200 devices without resulting in water damage or other artifact damage.



-Data centers are crucial to the running of many businesses and organizations because they contain enormous volumes of vital data. System FM200 can defend against fires that can result in data loss or disruption.



-Control rooms: Control rooms are often used in industrial and manufacturing sectors to monitor and manage complex processes. FM200 devices defend against fires that might block these processes and cause significant damage.





-Medical and research facilities: These businesses commonly use delicate supplies and equipment that need to be protected against fire. FM200 systems can extinguish fires without damaging the materials or tools.







                                                                                               Secure Your Archive With Red FM200 Automatic Fire Suppression Extinguishing System 4.2Mpa 40L 3





































Secure Your Archive With Red FM200 Automatic Fire Suppression Extinguishing System 4.2Mpa 40L 4







































Secure Your Archive With Red FM200 Automatic Fire Suppression Extinguishing System 4.2Mpa 40L 5

































Packages



We always pack it with polyfoam firstly and then put it into a wooden case. Sometimes, in order to meet with customers or the safety requirement, we will make a pallet for the goods.



                                                                                                            Secure Your Archive With Red FM200 Automatic Fire Suppression Extinguishing System 4.2Mpa 40L 6







After-Sale Service


• We have an efficient sales and after sales team to promise slove all client's question in time.
• We provide 8×6 hrs technical support and service.
