IG55 Argonite Fire System Non - Conductive Non - Corrosive Agent For Data Centers Control Rooms

Product Details:
Place of Origin: China
Brand Name: Xingjin
Certification: CAL,CMA,CNAS,ILAC-MRA,CCC
Model Number: QMDY30/80, QMDY20/80
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: negotiation
Packaging Details: Plywood outer box with bubble bag or paper
Delivery Time: 10-15 working days
Payment Terms: L/C, D/P, T/T, Western Union, Paypal, Credit card
Supply Ability: 300 sets per month
  • Detail Information
  • Product Description

Detail Information

Cylinder Volume: 80L Pattern Of Extinguishing: Enclosed Flooding
Agent: IG55(50% Nitrogen, 50% Argon ) Working Pressure: 30MPa, 20MPa
Color: Red Max. Working Pressure: 36.6 MPa, 23.2MPa
Min. Working Pressure: 27MPa, 18MPa System Start Mode: Electrical Automatic, Electrical Manual, Mechanical Emergency Start
High Light:

IG55 Argonite Fire System Non Corrosive

,

IG55 Argonite Fire System Non Conductive

Product Description

IG55 Argonite fire system

IG55 Argonite fire system





IG55 Argonite Fire System Non - Conductive Non - Corrosive Agent For Data Centers Control Rooms 0






Description



A clean agent fire suppression system is illustrated by the IG55 automatic fire extinguishing system. It is intended to extinguish fires quickly and effectively without causing damage to delicate equipment or leaving residue behind. The procedure develops a non-conductive, non-conductive, and ecologically benign fire-extinguishing agent by mixing two naturally occurring gases, argon and nitrogen.



The IG55 system is regularly used to safeguard locations containing valuable and sensitive technology, such as data centers, server rooms, communication hubs, and control rooms. When a fire detection system detects heat or smoke, an extinguishing agent is automatically discharged into the enclosed space.



The IG55 system extinguishes fires by lowering the amount of oxygen in the confined space to a level that prevents combustion. The system is meant to extinguish fires rapidly and effectively while inflicting the least amount of damage to the building or the equipment it is protecting.



The IG55 system features a straightforward, dependable architecture that makes it appropriate for a wide range of applications. It is really simple to set up and maintain. The system is also very customizable, with the ability to be modified to fulfill specific fire protection needs.



The IG55 automatic fire extinguishing system protects irreplaceable facilities and equipment quickly and effectively while reducing damage and downtime.



Parameters



No. Specification Technical Parameter
1 Working Pressure 20MPa 30MPa
2 Device Model QMDY20/80 QMDY30/80
3 Capacity 80Ltr 80Ltr
4 Outside Diameter of Cylinder Φ279mm Φ267mm
5 Height of Cylinder 1610+70mm 1770±10mm
6 Max Working Pressure 23.2MPa 36.6MPa
7 Min Working Pressure 18MPa 27MPa
8 Spraying Time ≤120s
9 Power DC24V/1.6A
10 Nitrogen Pressure of Driving Device 6.0±1.0MPa(20℃)
11 Condition of Reserving Room for Container temperature: 0~50℃








Application



The IG55 automatic fire extinguishing system can be used in any situation where fire safety is crucial. Listed below are a few situations where the IG55 system might be used:

  1. The computer network Data centers, which are prone to fire damage, house critical servers and computer systems. The IG55 system is ideal for protecting these areas since it can quickly extinguish flames without causing damage to sensitive electrical equipment.

  2. Installing the communication infrastructure To support communication networks, telecommunications facilities require gear such as switches, routers, and servers. The IG55 system, which provides continuous communication in the event of a fire, can protect these installations.

  3. Unique objects and irreplaceable records are frequently housed in museums and archives. The IG55 system can protect these items from fire damage, preserving them for future generations.

  4. Substations and control rooms are two examples of locations where the equipment required to keep the electricity flowing continuously is housed. The IG55 system can lessen the likelihood of outages and downtime by securing these areas.

  5. Locations with combustible materials, such as chemical plants and manufacturing complexes, can provide a high fire risk. The IG55 system can successfully protect against fire while lowering the risk of product and equipment damage.

Overall, the IG55 automatic fire extinguishing system is a versatile choice for a range of applications that demand dependable and efficient fire protection.



Packages



To ensure the safe transportation and delivery of the FM200 fire suppression system, a careful packaging process is implemented. Here, let's expand on the packaging procedures involved:

  1. Polyfoam Packaging:
    The FM200 fire suppression system is first packed with polyfoam, a lightweight and cushioning material. The polyfoam provides a protective layer around the components, absorbing shocks and vibrations that may occur during handling and transportation. This packaging step helps prevent damage to the system and ensures its integrity upon arrival.

  2. Wooden Case:
    After the polyfoam packaging, the FM200 fire suppression system is placed inside a sturdy wooden case. The wooden case provides an additional layer of protection, shielding the system from external impacts, moisture, and other potential hazards. The case is carefully constructed to fit the dimensions of the system, ensuring a secure and snug fit.

  3. Palletization:
    In certain situations, such as when meeting specific customer requirements or complying with safety regulations, palletization may be implemented. Palletization involves placing the wooden case containing the FM200 system onto a pallet, a flat platform typically made of wood or plastic. This method facilitates easy handling and transportation of multiple units, as the pallets can be efficiently loaded and unloaded using forklifts or pallet jacks.

Palletization offers several benefits, including improved stability, reduced risk of damage during transit, and streamlined logistics. It allows for efficient storage, handling, and organization of the FM200 systems, particularly when dealing with larger quantities or bulk shipments.

By employing these packaging procedures—polyfoam packaging, wooden case protection, and optionally palletization—the FM200 fire suppression system is packaged securely to withstand the rigors of transportation. These measures ensure that the system arrives in optimal condition, ready for installation and deployment to effectively protect the intended environment against fire hazards.



IG55 Argonite Fire System Non - Conductive Non - Corrosive Agent For Data Centers Control Rooms 1





Advantages

1. A 30MPa system uses 25% to 50% fewer extinguisher cylinders than a 15MPa system.

2. The overall use value and utilization rate of the building are boosted by dramatically lowering the floor area between the cylinders.
3. A consistent low pressure release of 6MPa reduces the cost of the pipes and other system components.

4. The continuous release pressure of 6 MPa provides a more reliable and effective pressure with a transmission range of up to 200 meters.

5. The complete system will discharge with little pressure, increasing safety and reducing damage to the machinery, people, and building structure.

6. The outside continuous pressure-relief mechanism considerably reduces the probability of system failure and is simple to disassemble and maintain because it only maintains pressure during system discharge.

7. Because of the ease of disassembly and secondary filling with agent after discharge, the system can be put into service immediately without replacing any of the components.

8.It also makes installing and positioning the safety buckle easier by lowering the size of the opening hole in the gas pressure relief port. Furthermore, it directly reduces the input cost of the safety pressure releasing system.

9. IG55 fire extinguishing system can be widely used in important places that need rapid response to fire. There are workers, sudden fires and sensitive to chemical reactions on the site of the protection zone, the fire extinguishing system can effectively protect the safety of personnel and property.



Mimic Diagram





Multiple cylinders for multiple zones



IG55 Argonite Fire System Non - Conductive Non - Corrosive Agent For Data Centers Control Rooms 2





Multiple cylinders for one zone



IG55 Argonite Fire System Non - Conductive Non - Corrosive Agent For Data Centers Control Rooms 3



Company Introduction



Strategically situated in Guangzhou, a city renowned for its easy access to transit and scenic surroundings, is Guangzhou Xingjin Fire Equipment Co., Ltd. Guangzhou is crucial in promoting communication and trade since it is situated where China's home market meets the international arena. Our business makes the most of this favorable location to position itself as the industry's top manufacturer.



We are dedicated to the study and development of HFC-227ea (FM200) fire suppression systems at Guangzhou Xingjin Fire Equipment Co., Ltd. Program design specialists, adept installation technicians, quality inspectors, and a quick-response after-sales service staff make up our committed team of professionals. In order to satisfy the demands of our clients, we work together to create superior goods and solutions.



Our range of FM200 products has gained widespread popularity and enjoys extensive usage across various sectors. These include:

  • Pipe Network FM200 Fire Suppression System: This system utilizes a network of pipes to distribute FM200 agent throughout the protected area, ensuring comprehensive fire suppression coverage.
  • Cabinet Type FM200 Fire Suppression System: Designed specifically for cabinet enclosures, this system provides targeted fire protection for valuable equipment and materials housed within cabinets.
  • Automatic FM200 Fire Extinguisher (Wall-mounted Style): This ceiling-mounted automatic extinguisher is an efficient and compact solution for fire suppression, particularly suitable for areas with limited space.
  • Fire Detecting Tube Suppression System: This innovative system employs fire detecting tubes that react to heat and automatically discharge the FM200 agent, swiftly suppressing fires.
  • Automatic Fire Suppression Tube: This tube-based system is designed to detect and suppress fires within confined spaces, making it ideal for use in small enclosures or equipment compartments.

Thanks to our unwavering commitment to delivering high-quality products and exceptional customer service, Guangzhou Xingjin Fire Equipment Co., Ltd. has garnered a strong reputation in the Chinese market. We are proud to have earned the trust and satisfaction of our.



IG55 Argonite Fire System Non - Conductive Non - Corrosive Agent For Data Centers Control Rooms 4

IG55 Argonite Fire System Non - Conductive Non - Corrosive Agent For Data Centers Control Rooms 5IG55 Argonite Fire System Non - Conductive Non - Corrosive Agent For Data Centers Control Rooms 6

IG55 Argonite Fire System Non - Conductive Non - Corrosive Agent For Data Centers Control Rooms 7

IG55 Argonite Fire System Non - Conductive Non - Corrosive Agent For Data Centers Control Rooms 8


Why Choose Us

  • 5 years quality guarantee
  • Xingjin is running in a high efficiency management system
  • Advanced equipments & professional engineers to promise all products are quite satisfactory.
  • We provide 8×6 hrs technical support and service.

After-Sale Service

  • We have an efficient sales and after sales team to promise slove all client's question in time.
  • We provide 8×6 hrs technical support and service.

FAQ



Q1: Are you a manufacturer or a trading company?

A1: We are a manufacturer.



Q2: Is OEM products available?

A2: Yes, we welcome your own design and drawing.



Q3: Where is your factory? Can I visit it?

A3: Our factory locates in Shilou, Panyu, Guangzhou, Guangdong, China.

Of course yes. We always welcome and wait for your visit.



Q4: How can I get to your factory?

A4: Because of the convenient transportation here, you can take a taxi or come here by subway. If you come here by subway, you need to take the line four and get off at Shiqi station. Then walk out the station for taking No. 126 bus and get off at Yuexi station.
