180L Type Hfc227ea Fire Suppression System With Multiple Zones Controlled

Product Details

Place of Origin: China

Brand Name: xingjin

Certification: CAL,CMA,CNAS,ILAC-MRA,CCC

Payment & Shipping Terms

Minimum Order Quantity: 2 set system

Price: negotiation

Packaging Details: Plywood outer box with bubble bag or paper

Delivery Time: 15-20 working days after payment or receipt of L/C

Payment Terms: T/T, L/C

Supply Ability: 30000 set system

Get Best Price
Product Details
High Light:

gas fire suppression system

,

gas fm 200

,

180l hfc227ea fire suppression system

Pattern Of Extinguishing:
Totally Flooding
Weight:
80kg
Volume Of Cabinet:
627L
Capacity Of Cylinder:
180L
Agent:
Htc-227ea
Standard Of Examination:
GB25972-2010
Pattern Of Extinguishing:
Totally Flooding
Weight:
80kg
Volume Of Cabinet:
627L
Capacity Of Cylinder:
180L
Agent:
Htc-227ea
Standard Of Examination:
GB25972-2010
Product Description

180L Type Hfc227ea Fire Suppression System With Multiple Zones Controlled



Parameter:



No. specification Technical Parameter
1 Filling pressure 2.5Mpa
2 Relief pressure 5.0±0.225Mpa
3 Spraying time ≤10s
4 Working temperature 0~50℃
5 Power DC24V/1.6A
6 max working pressure 4.2Mpa



Description:



    Fm200(htc-227ea) is a kind of colorless and tasteless and non-corrosive and electricity-insulating gas without residue and pollution after extinguishing. And ODP of it is zero. It is a friendly-environment gas to be used for extinguishing. Also, because of such feature, it can be used in special place where electrical fire is easy to happen.



    Combined with extinguishing device and electronic accessories, the whole system can be actuated automatically. It can monitor the situation of protective region through detectors and then it can also start the extinguishing device through solenoid actuator automatically. So the whole system can achieve automation totally. Therefore, it can avoid that there is no one who notice the fire when it happens and also it saves much money for employment to supervise the protective area.



Applications:



    Electronic computer room, a data processing center, telecommunications facilities, process control, expensive medical equipment, industrial equipment, library, museum and art gallery, clean room, anechoic chamber, etc.



    The place where the fire is easy to happen, like paint-spraying production line, aging-electrical equipment, rolling machine, printing machine, oil switch, oil immersed transformer, melt impregnating tank, tank, large generators, drying equipment, cement production process of pulverized coal, and the ship's engine room, cargo hold, etc.





Competitive Advantage:



    In terms of description of agent, one of its competent advantages is that it can be used for all kinds of class fires except metal fire. And it is clean agent. There is no residue and pollution after extinguishing.



    It is very efficient for you to protect your possession. Since it is a system, it include extinguishing device to put out fire at short time, specially, shorter than 10 second. It means all agent will be discharged in so short time. Then it will be flooding overall. In addition, it has time-delay mechanism. It is around 2 minute. It means when fire happens, there is enough time left to evacuate people from hazardous place.



    Different from piped network type of fm200 automatic fire suppression system, it will be simple to install.



    Because there is no pipeline installation. If your protective zone is relatively small and there is no multiple zones more than three, it will save much money than the former.



Working principle:



    Here is the illustration of working principle to whole system,





                   180L Type Hfc227ea Fire Suppression System With Multiple Zones Controlled 0



Simulated diagram:



    Below attached is one mimic diagram of single cabinet type of fm200 automatic fire suppression system,





                180L Type Hfc227ea Fire Suppression System With Multiple Zones Controlled 1





                    180L Type Hfc227ea Fire Suppression System With Multiple Zones Controlled 2
