30MPa IG541 Inergen Gas Fire Suppression System For Minimal Damage

Product Details:
Place of Origin: China
Brand Name: Xingjin
Model Number: QMH20/80, QMH30/80
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: negotiation
Packaging Details: Plywood outer box with bubble bag or paper
Delivery Time: 10-15 working days
Payment Terms: L/C, D/P, T/T, Western Union, Paypal, Credit card
Supply Ability: 300 sets per month
  • Detail Information
  • Product Description

Detail Information

Cylinder Volume: 80L Capacity: 23.9kg(20MPa), 33.56kg(30MPa)
Pattern Of Extinguishing: Enclosed Flooding Agent: IG541(52% Nitrogen, 40% Argon, 8% Carbon Dioxide)
Working Pressure: 20MPa, 30MPa Color: Red
High Light:

Inergen Gas Fire Suppression System


IG541 Inergen Gas Fire Suppression System


30MPa Inert Gas Fire Suppression System

Product Description

30MPa IG541 Inergen Fire Suppression System




The IG541 automatic fire extinguishing system, another type of clean agent fire suppression system, is designed to quickly and effectively extinguish fires without damaging delicate equipment or leaving any trace. The method uses a mixture of three naturally existing gases—nitrogen, argon, and carbon dioxide—to create a non-conductive, non-conductive, and environmentally safe fire-extinguishing agent.


The IG541 system is frequently used to secure locations like data centers, server rooms, communication facilities, and control rooms. The mechanism rapidly disperses the extinguishing chemical into the confined space when heat or smoke are detected. A fire detection system turns the system on.


The IG541 system extinguishes a fire by reducing the oxygen content of the enclosed space to a level below which combustion is unable to proceed. The system is designed to promptly and effectively extinguish flames with the least amount of disruption to the building or protected equipment.


The design of the IG541 system is uncomplicated and reliable, making it simple to install and maintain. It is excellent for a range of applications. The system is very adaptable and may be configured to meet various fire protection requirements.


The IG541 system has the advantage of being an environmentally safe option for fire suppression because it has a low potential for ozone depletion and global warming. Additionally, the system is safe to use in occupied spaces because the extinguishing chemical is non-toxic and doesn't produce any hazardous byproducts.


Overall, the IG541 automatic fire extinguishing system minimizes damage and downtime while providing timely and effective protection for irreplaceable facilities and equipment.



No. Specification Technical Parameter
1 Working Pressure 20MPa 30MPa
2 Device Model QMH20/80 QMH30/80
3 Capacity 80Ltr 80Ltr
4 Filling Capacity of Gas 22.37kg 33.56kg
5 Filling Rate 0.29kg/L 0.42kg/L
6 Outside Diameter of Cylinder Φ286mm Φ267mm
7 Height of Cylinder 1910mm 1770mm
8 Max Working Pressure 23.2MPa 36.6MPa
9 Min Working Pressure 18MPa 27MPa
10 Spraying Time ≤120s
11 Power DC24V/1.6A
12 Nitrogen Pressure of Driving Device 6.0±1.0Mpa(20℃)
13 Condition of Reserving Room for Container temperature: 0~50℃



Leaching tank, drying equipment, paint spraying booth, electrical instrument room, control center, library, archives, treasure trove of cultural artifacts, etc. are just a few examples of the rooms that are available.



We always pack it with polyfoam first and then put it into a wooden case. Sometimes, in order to meet with customers or the safety requirement, we will make a pallet for the goods.

30MPa IG541 Inergen Gas Fire Suppression System For Minimal Damage 0


With the exception of metal fires, one of the agent's advantages in terms of its description is that it may be used for all classes of class fires. It is a clean agent, as well. After being put out, the fire leaves no traces of pollutants.


Another is the expertise of the IG541 extinguishing system in handling critical assets or equipment. Your goods won't suffer any damage as a result. It is an effective fire suppression system that is also reasonably priced.


By doing this, you can properly protect your possessions. It has an extinguishing mechanism built into the system to swiftly put out a fire, preferably in less than 10 seconds. It suggests that all agents will be released in this manner promptly. There will then be extensive flooding. There is a time delay mechanism included as well. It takes two minutes or so. It implies that, in the event of a fire, enough time will be available to safely evacuate everyone.


It can make it possible for many zones to be safely managed by one system. This will result in significant cost savings for expansive and multiple zones.


Mimic Diagram

Multiple cylinders for one zone


30MPa IG541 Inergen Gas Fire Suppression System For Minimal Damage 1



Multiple cylinders for multiple zones


30MPa IG541 Inergen Gas Fire Suppression System For Minimal Damage 2
