FM200 automatic fire tube for telecommunication base station protection

Name: FM200 automatic fire tube for telecommunication base station protection
Brand: Guangzhou Xingjin Fire Equipment Co.,Ltd.
SKU: QMP40/4.2, QMP70/4.2, QMP100/4.2, QMP120/4.2, QMP150/4.2, QMP180/4.2, QMP70/5.6, QMP90/5.6, QMP120/5.6
Price: 831.50 USD
Availability: InStock

Product Details

Place of Origin: Guangzhou,China

Brand Name: XINGJIN

Certification: CMA,CNAS,ILAC-MRA,CCC

Model Number: QMP40/4.2, QMP70/4.2, QMP100/4.2, QMP120/4.2, QMP150/4.2, QMP180/4.2, QMP70/5.6, QMP90/5.6, QMP120/5.6

Payment & Shipping Terms

Minimum Order Quantity: 2 set system

Price: Pricing based on quantity

Packaging Details: Wooden Box Or Plywood Outer Box With Bubble Bag Or Paper

Delivery Time: According to product quantity

Payment Terms: T/T, L/C

Supply Ability: 30000set/month

Get Best Price

Product Details

Product Description

Product Details

Highlight:

Cylinder Volume:	40L, 70L, 90L, 100L, 120L, 150L, 180L	Capacity Of Gas:	38kg, 66.5kg, 85.5kg, 95kg, 114kg, 142.5kg, 171kg
Agent:	Hfc-227ea (FM200)	Storage Pressure:	4.2 Mpa
Fire Extinguishing Agent Spraying Time:	≤10s	Fire Extinguishing Agent Filling Density:	≤950kg/m3
Drive Device Air Source Pressure:	6.0Mpa(20℃)	System Working Power Supply:	AC 220V DC 24V 1A
System Operating Environment Temperature:	0℃～50℃	System Protection Limit Area:	800m²
System Protection Limit Volume:	3600m³

Cylinder Volume:	40L, 70L, 90L, 100L, 120L, 150L, 180L
Capacity Of Gas:	38kg, 66.5kg, 85.5kg, 95kg, 114kg, 142.5kg, 171kg
Agent:	Hfc-227ea (FM200)
Storage Pressure:	4.2 Mpa
Fire Extinguishing Agent Spraying Time:	≤10s
Fire Extinguishing Agent Filling Density:	≤950kg/m3
Drive Device Air Source Pressure:	6.0Mpa(20℃)
System Working Power Supply:	AC 220V DC 24V 1A
System Operating Environment Temperature:	0℃～50℃
System Protection Limit Area:	800m²
System Protection Limit Volume:	3600m³

Product Description

Pipe network Suspended Extinguishing Equipment

Product Introduction:
Heptafluoropropane fire extinguishing systems are currently widely used in most parts of the world. Heptafluoropropane is a colorless, odorless gas with zero ozone depletion potential, meeting environmental standards. It is clean, low-toxic, has excellent electrical insulation, and offers high fire extinguishing effectiveness, making it an ideal alternative to halons.
The HFC-227ea fire extinguishing system has the advantages of complete design parameters, perfect functions, accurate and reliable operation, long-term storage without leakage, simple installation and commissioning, and convenient operation and maintenance. The system is mainly composed of automatic alarm controller, storage device, valve drive device selection valve, one-way valve, pressure signal device, frame, sprinkler, pipe network and other components.

According to the use requirements, it can be composed of independent unit systems, and the combined distribution system can implement fire protection for single zone and multiple zones respectively.

Application range:

Suitable for extinguishing the following types of fire	It should not be used to extinguish fires of the following substances
(1) Electrical fires; (2) Fires on liquid surfaces or fusible solids; (3) Fires on solid surfaces; (4) Gas fires where the gas source can be cut off before extinguishing the fire.	(1) Chemical products and mixtures containing oxidants, such as nitrocellulose and sodium nitrate; (2) Active metals, such as potassium, sodium, magnesium, titanium, zirconium, and uranium; (3) Metal hydrides, such as potassium hydride and sodium hydride; (4) Chemical substances that can decompose on their own, such as hydrogen peroxide and hydrazine.
